Complex Salt Spray Test Chamber DGBell BE-8209-12m³
Have you ever encountered a situation where a product did not meet the durability requirements when exposed to a saltwater environment? Don't worry, the DGBell BE-8209-12m³ Salt Spray Test Chamber is the solution to your problem.
Quality Standards
Complex Salt Spray Test Chamber DGBell BE-8209-12m³ is a unique testing device designed to simulate the harshest saltwater environment to test the durability of batteries and systems.
The product is manufactured according to GB/T4 Part 5.5.2 standards and tested under GT/T2423.17 test conditions, ensuring maximum quality and reliability.
The product meets the UL 2580 technical standards.
Product Usage
This test chamber can simulate a complex salt spray environment with controlled temperature of (35 ± 2) ℃ and pH ranging from 6.5-7.2.
The test specimens will be exposed to the salt spray for 24 hours, with 8 hours of salt spraying and 16 hours of keeping it constant.
With a total of 6 test cycles, you can be confident that your product will be thoroughly tested.
Product Features
Complex Salt Spray Test Chamber DGBell BE-8209-12m³ offers several advantages and standout features compared to other products on the market:
- Large size: With a capacity of 12m³, the DGBell BE-8209-12m³ can accommodate multiple test samples simultaneously, increasing testing efficiency and saving time.
- Precise temperature control: This device has the capability to precisely control the temperature within the range of (35 ± 2) ℃, ensuring a stable and compliant testing environment.
- Stable pH level: The DGBell BE-8209-12m³ Salt Spray Test Chamber maintains the pH level of the salt solution within the range of 6.5-7.2, enabling accurate product quality testing.
- Space-saving design: The intelligent design of the test chamber helps save space in the laboratory, allowing for easy installation and mobility when needed.
- Compliance with international standards such as GB/T4 and GT/T2423.17, ensuring high quality and reliability.
- Simple and user-friendly control panel enables easy setup and control of testing parameters.
- Reliable quality: The product is manufactured by DGBell, a leading brand in the testing industry, ensuring product quality and excellent technical support.
These outstanding advantages and features make Complex Salt Spray Test Chamber DGBell BE-8209-12m³ a top choice for manufacturers and professional laboratories.
Product specifications:
|
Model |
BE-8209-12m³ |
|
Internal Dimension: |
W2000 X D3000 X H2000 mm |
|
External Dimension: |
W2400 X D5000 X H3000 mm |
|
Max Load: |
1000KG for battery pack |
|
Temp. Range: |
0℃～+85℃ |
|
Temp. Fluctuation: |
±0.5℃ |
|
Temp. Deviation: |
2℃ |
|
Spray Capacity: |
1~2mL/80cm2/hr (Collect at least 16 hours, take the average ) |
|
Spray Pressure: |
1.00±0.01kgf/cm² |
|
Resolution: |
Temp: 0.01℃, Humidity:0.01%R.H. |
|
Humidity Range: |
30%–98%R.H. |
|
Humidity Fluctuation: |
±3%R.H. |
|
Potion PH: |
Neutral 6.0～7.0 Acidity 3.0～3.1 |
|
Spray Solution PH: |
Neutral 6.5～7.2 Acidity 3.1～3.3 |
|
Test Time Range: |
1S ～ 9999H (Settable) |
|
Control Mode: |
Touch screen programmable control PLC, networking; mobile phone APP alarm; with USB interface, with RJ485 interface can be connected to computer control, exclusive network control software. Remote monitoring and data acquisition. |
|
Internal material: |
Acid and alkali resistant SUS316 material |
|
External material: |
Cold and heat resistant steel plate with spray coating |
|
Cooling Mode: |
Air cooling / water cooling |
|
Total Weight: |
Approx 7 Tons |
|
Power Supply: |
AC 380V, 55KW |
|
Other Auxiliary Functions: |
*Main-subsidiary type trolley for the specimen in and out of the test chamber.*Explosion-proof, Pressure relief, Smoke Exhaust, Fire extinguishing, Video monitoring. |
"Don't let the quality of your products be compromised by subpar testing equipment. Contact us today to learn more about how the DGBell BE-8206-1500 Battery Pack Drop Tester can support you in ensuring the best battery quality. Let us help you elevate the quality of your products to new heights!"
