Application
The Vibration Test System is a simulation of the various environments encountered in the manufacturing, assembly, transportation and use phases of execution. It is primarily used to identify the ability of a product to withstand environmental vibrations. It is suitable for research, development, quality control and manufacturing of electronics, electromechanical, optoelectronics, automobile locomotives, toys and other industries.
Standards
- - IEC 62133-2017
- - ECE R100
- - UL 1642
- - UN 38.3
Technical Parameters
| Model | BE-EV-203 |
|---|---|
| Rated Sine Excitation Force | 3000 N |
| Rated Random Excitation Force | 3000 N |
| Shock Excitation Force | 6000 N |
| Frequency Range | 5-4,000 Hz |
| Max. Displacement | 25mm |
| Rated Speed | 2 m/s |
| Rated Acceleration | 500 m/s2 |
| First-order resonant frequency | 2,900 Hz±5% |
| Max. Loading | 100 kg |
| Vibration Frequency | 3 Hz |
| Working Table Diameter | Ф150 mm |
| Moving Parts Equivalent Weight | 2 kg |
| Dimension | L764×W530×H660 mm |
| Single Vibration Table Weight | Approx. 480kg |
| Cooling Method | Forced air cooling |
