DGBELL BE-SUN Customized solar simulation test chamber

Contact
Brand: DGBELL Product code: BE-SUN

Bell’s Customized Solar Simulation Test Chambers provide an essential testing environment for solar products, complying with the DIN75220 standard. We offer adjustable irradiance levels between 600 to 1200 W/m² and customizable areas to fit various product sizes. The chambers are equipped with temperature and safety sensors, ensuring reliable and safe operations. With a user-friendly touchscreen interface, these chambers are designed for efficient and accurate solar product testing.

Contact us for a consultation

0936093289 (Time: 8:00 am - 5:00 pm)

Product Specifications:

  • Standard: Compliant with DIN75220 standard.
  • Irradiance Intensity Range: 600 to 1200 W/m².
  • Customizable Irradiated Area: Can be customized according to customer requirements.
  • Control Interface: Touchscreen control interface for easy operation and monitoring.

Key Features:

  1. Irradiance Intensity Adjustment: Adjustable irradiance intensity to simulate the performance of solar products under different lighting conditions.
  2. Temperature Control: Precise control of the temperature inside the chamber to meet various testing requirements.
  3. Humidity Control: Optionally, humidity control can be added to simulate different environmental humidity conditions.
  4. Customizable Irradiated Area: Can be tailored to different irradiated areas according to customer needs to accommodate various sizes of solar products.
  5. Reliability and Stability: Designed and manufactured to meet standard requirements, ensuring stable operation and reliability of the system.



Model BE-SUN-6060 BE-SUN-2615 BE-SUN-3026 BE-SUN-4526 BE-SUN-5230
Operating Environment Temperature / Humidity: +5~35°C / ≤ 90% RH
Control Method Independent cold end and hot end PID adjustment, with both heating and cooling continuously adjustable.
Performance metrics
Irradiated Area (mm) 600*600 2600*1500 3000*2600 4500*2600 5200*3000
Irradiance Intensity 150~250W/ ㎡
Spectral Range 280~400nm
Uniformity ≤ 15%
UVB Content 3~10%(with the use of filters, can achieve a better range of 5~9%)
UVC Proportion Virtually None
Sample Temperature Range 60±5℃
internal dimensions
W(mm) 600 2800 3200 4700 5400
D(mm) 600 1700 2800 2800 3200
H(mm) 1000 1800 1800 1800 1800
External dimensions (excluding lifting mechanism and light source height)
W(mm) 1300 3000 3400 4900 5600
D(mm) 1700 3500 4600 4600 5200
H(mm) 2300 2400 2400 2400 2400
Cooling method Air-cooled/Water-cooled
Power supply AC 380V; 50Hz (3-phase +N+PE)
Rated power (KW) 16 35 50 77 101
Rated current (A) 24 59 91 142 188
Standard configuration 1.Observation window
2.Sample rack
3.UV sensor
4.Temperature sensor
5.USB port
6.Cable hole with silicone plug Φ100mmx2 (on both sides of the chamber)

Optional configuration 1.LED lighting
2.External socket 220V 10A
3.Electronic load
4.LAN interface and remote control software
5.Other non-standard configurations
Performance indicators are measured at room temperature of +25°C, with sensors positioned at the air handling unit's air outlet.

Notes:

  • - Ensure that the design and manufacturing of the chamber comply with the requirements of the DIN75220 standard to ensure the accuracy and reliability of test results.
  • - When using the chamber, follow the operating procedures in the user manual to ensure the safe and stable operation of the system, and perform regular maintenance and inspections to keep the equipment in good condition.

Contact GPower Vietnam for detailed information about the product and accompanying warranty and maintenance services.
