With a temperature resolution of up to 0.01 degrees Celsius, the BTT-D2-216A test chamber can accurately measure and test all parameters related to the material aging process. This ensures that the product will always meet the highest quality standards.
Equipped with smart features such as a versatile display screen, safety alerts, and automatic shutoff in case of malfunction, the product is designed to meet safety standards and prevent undesirable incidents.
In addition, the BTT-D2-216A is designed for energy efficiency, minimizing its impact on the environment.
The BTT-D2-216A is manufactured by DGBell, one of GPower Vietnam's reputable partners, ensuring the highest product quality and fast, professional technical support and maintenance for customers.
Product specifications:
|
Model |
BTT-D2-216A |
BTT-D2-360A |
|
Single Cabinet Inner Dimension |
W600 X D600 X H600 MM |
W1000 X D600 X H600MM |
|
External Dimension |
W1340 * D1085 * H1765mm |
|
|
Structure Mode |
An integral structure with upper and lower cabinets |
|
|
Temperature Range |
Room temperature +10 C to +1 50 C |
|
|
Temperature Fluctuation |
± 0,3 ℃ |
|
|
Heating Time |
RT + 10 ～ + 100 ° C for about 10 minutes |
|
|
Temperature Uniformity |
≤ ± 2 ℃ （No load, constant state) |
|
|
Observation Window |
Explosion-proof glass with explosion-proof membrane |
|
|
Cooling Mode |
Air cooling |
|
|
Controlling Mode |
Touchscreen programmable control PLC, with USB interface, with RS485 interface can be connected to computer control, special network control software, convenient remote monitoring, data acquisition |
|
|
Inner Chamber Material |
1.0MM thick SUS304# mirror stainless steel, sprayed with Teflon insulation |
|
|
External Chamber Material |
1.2 MM thick Galvanized sheet, dusting painted with high temperature plasticized coating. |
|
|
Power Supply |
AC380V 50HZ |
AC380V 50HZ |
|
Safety Protection |
Automatic explosion-proof pressure relief device, explosion-proof chain, tri-color light alarm device, remote control, smoke exhaust device, fire extinguishing device, etc. |
|
|
Cable Port |
¢100mm each opening one with soft silicone plug and stainless steel cover |
|
|
Extension Function |
Provide communication protocol, able to accompanied use with charge and discharge machine |
|
Besides the BTT-D2-216A, GPower Vietnam also provides various other products in the field of reliability testing and material testing to meet all customer needs. DGBell products are designed with smart features, high accuracy, and energy efficiency, which help save costs and ensure safety during use.
If you are in need of products in this field, please contact us for the best consultation and support.
